Collection
Finishing
Satin Stainless,
Gunmetal,
Matte Black,
Matte White,
Oil Rubbed Bronze,
Polished Brass,
Polished Gold,
Polished Stainless,
Satin Brass,
Satin Bronze,
Satin Champagne,
- Site Sizable: Modify length and locate outlet placement on site
Waterproofing: PVC/Vinyl liner, Lead/copper pan, Hot mop, Rubber liner, Fiberglass
16 gauge, 304 stainless steel Slot and Channel
Overall width: 2-3/4″ Min. height above subfloor*: 1-13/16″
Capacity: 9 gallons per minute per outlet. Additional outlets may be added to increase flow rate.
Requires 2″ clamp down floor drain with 2″ throat (strainer size). Not included in complete kit.
- Manufacturer's Part Number(s): S-SLOTAS 48 SR (Satin Brass), S-SLOTAS 48 SS (Satin Stainless), S-SLOTAS 48 SC (Satin Champagne), S-SLOTAS 48 SB (Satin Bronze), S-SLOTAS 48 PS (Polished Stainless), S-SLOTAS 48 PB (Polished Brass), S-SLOTAS 48 ORB (Oil Rubbed Bronze), S-SLOTAS 48 MW (Matte White), S-SLOTAS 48 GM (Gunmetal), S-SLOTAS 48 BK (Matte Black), S-SLOTAS 48 PG (Polished Gold)
