Collection
Finishing
Chrome,
Dark Chrome,
Brushed Dark Platinum,
Brushed Platinum,
Brushed Durabrass (23Kt Gold),
Brushed Dark Brass (Pvd),
Brushed Bronze (Pvd),
Brushed Dark Bronze (Pvd),
- Trim parts
Rain panel with 3 different spray types
AQUACIRCLE RAIN: Circular rain curtain, flow rate max. 1.8 gpm (at 3 bar)
TEMPEST RAIN: Natural rain, flow rate max. 1.8 gpm (at 3 bar)
DIAMOND RAIN: Rain ring, flow rate max. 1.8 gpm (at 3 bar)
Technical data:
Outer diameter: 23-7/8", diameter of opening: 18-1/4"
Weight: 13 lbs
Electric:
#
Separate LED Power supply
350mA (CC)
Input LED Power supply
350mA (CC)
Input 100-240V AC 50-60Hz
Technology: LED, not dimmable
Spot lighting
#
Output LED Power supply
#
Output Specification LED Power supply
IP67
SELV (Safety Extra Low Voltage)
Class 2
Ceiling module power supply
Connecting cable 27-1/2"
LED color temperature: approx. 3000 K
Lights protected against splashing
Light switch not included
Environment
#
Planning tips:
Not suitable for outdoor use.
Not suitable for use in a steam room.
Not suitable for use in chlorinated or salty environments.
Observe the regulations concerning protected zones specified in DIN VDE 0100, Part 701 (IEC 60364-7-701).
Notes:
Recommended control unit: xTool
Includes lights rated at energy efficiency class
- Manufacturer's Part Number(s): 36200809-000010 (Chrome), 36200809-420010 (Brushed Bronze (Pvd)), 36200809-060010 (Brushed Platinum), 36200809-390010 (Brushed Dark Brass (Pvd)), 36200809-430010 (Brushed Dark Bronze (Pvd)), 36200809-990010 (Brushed Dark Platinum), 36200809-280010 (Brushed Durabrass (23Kt Gold)), 36200809-190010 (Dark Chrome)
